Pan Tilt Unit/Positioner
-
The pan and tilt positioner, also known as a pan tilt head or pan-tilt unit (PTU), is a two-axis (pan and tilt) electromechanical positioning device designed to provide precise and stable angular motion in the horizontal and vertical directions. It is widely used across multiple fields, including traditional video surveillance, as well as emerging applications such as drone detection and countermeasure systems, long-range monitoring, and multi-sensor platforms.
Driven by continuous research and development, our pan and tilt unit have been continuously upgraded with advanced control and mechanical technologies. These include preset positions, cruise paths, pattern scanning, guard positions, position query and feedback, absolute angle control, repeatable positioning, and high-precision worm gear transmission. Combined with ultra-slow speed control for long-range video surveillance, high positioning accuracy, and corrosion-resistant powder coating, our PTUs deliver stable and reliable performance in harsh outdoor environments, with protection ratings up to IP66.
Today, as a reputable Pan Tilt Unit supplier and one of the trusted surveillance camera suppliers, we provide a comprehensive range of pan-tilt heads to customers worldwide, covering small, medium, and large sizes, with payload capacities ranging from 3.5 kg to 200 kg. In addition, our deep customization services—including mechanical structure, load capacity, control interfaces, and environmental adaptation—are highly recognized and trusted by global customers.
Explore Our Diverse Range of ZIWIN CCTV Camera
3.5kg-10kg Duty Pan Tilt Head/Unit
Light duty small size pan tilt unit, with max load capacity up to 8kg/10kg(17.6lb/20.05lb). Designed as indoor/outdoor top load type pan tilt unit, it features variable speed, 360 degree continuous pan rotation, ±1°preset accuracy and IP66 ingress protection.
15kg-30kg Duty Pan Tilt Head/Unit
Best-selling medium size pan tilt motorized head, worm/gear drive, loading capacity 15kg/30kg (33.07lb/66.14lb), outdoor application, advanced features: absolute control, angle query, Pelco D extended commands control, 0.1 degree high precision and IP66 waterproof.
50kg-200kg Duty Pan Tilt Head/Unit
Heavy duty motorized pan tilt positioner, stepper motor with worm/gear drive, load capacity 50kg/80kg (110.23lb/176.37lb), 0.1 degree positioning accuracy, advanced features: absolute control, angle query, Pelco D extended commands control, IP 66 ingress protection.
Strength and Reliability for Heavy Duty Pan Tilt Units
ZIWIN heavy duty pan & tilt positioners are purpose-built for demanding surveillance and positioning applications. Designed for continuous operation in harsh outdoor environments, they deliver precise motion control, stable performance, and long-term reliability across a wide range of security and monitoring scenarios.
Precision Direct-Drive Positioning Precision Direct-Drive Positioning
High-accuracy servo control delivers repeatable positioning accuracy of up to ±0.01°, enabling stable and reliable control of payloads up to 120 kg for professional applications.
Smooth and Controlled Motion Smooth and Controlled Motion
Wide pan-tilt movement with flexible speed control supports both precision positioning and smooth scanning, ensuring consistent performance under varying operational demands.
Industrial-Grade Reliability Industrial-Grade Reliability
Built for harsh outdoor conditions, the robust mechanical design and industrial-grade components support reliable operation across a wide operating temperature range from -40°C to +70°C, ensuring long-term deployment stability.
Professional Deep Customization Services
ZIWIN provides professional deep customization services for Pan Tilt Unit solutions, enabling system integrators and project partners to tailor performance, structure, and interfaces to meet specific operational requirements across a wide range of surveillance, monitoring, and industrial applications.
Motion Speed Customization
Pan and tilt rotation speeds of the pan tilt system can be precisely customized to balance smooth motion, positioning accuracy, and response characteristics for different use cases.
Rotation Range Customization
Horizontal pan range and vertical tilt angles of the pan tilt positioner can be configured to suit various installation layouts and coverage requirements.
Payload Customization
The load capacity of the Pan Tilt Unit can be tailored based on payload weight, center of gravity, rotation speed, and operational angles to ensure stable and reliable operation.
Wiring and Slip Ring Customization
Custom wiring harnesses and connectors for the pan tilt system are available, including RF cables, high-current power lines, and signal cables integrated through slip rings.
Control Interface Customization
Control logic, communication protocols, and command interfaces of the pan tilt positioner can be adapted to customer-specified system architectures and control requirements.
Structural and Mechanical Customization
The mechanical structure, housing design, surface color, and connectors of the Pan Tilt Unit can be modified to enable seamless integration into specific platforms and environments.
Custom Configuration Available:
For optimal Pan-Tilt unit selection, please email your detailed technical requirements to sales@ziwincctv.com for expert consultation. As one of the leading pan & tilt positioners suppliers, we are committed to providing tailored solutions that meet your specific needs. Our expert team is ready to assist you in finding the perfect unit to enhance your system's performance and reliability.
How can I buy ZIWIN’s Pan Tilt Units?
To find out pricing and availability for ZIWIN’s Pan Tilt Units, please contact ZIWIN directly. Our technical sales team will provide a free, no-obligation quotation based on your payload requirements, operating environment, and application needs.
How do I choose the right payload capacity for a Pan Tilt Unit?
The required payload capacity of a Pan Tilt Unit depends closely on the weight, physical dimensions, and center of gravity of the mounted device. Factors such as operating angles, rotation speed, and installation orientation can also affect load requirements.
To ensure accurate selection and stable operation, we recommend consulting with ZIWIN’s technical experts.
What is a Pan Tilt Unit (PTU)?
Pan Tilt Unit is a motorized positioning system designed to precisely control the horizontal (pan) and vertical (tilt) movement of cameras or other payloads. ZIWIN Pan Tilt Units use high-accuracy control and robust mechanical design to provide stable positioning, smooth motion, and reliable operation in demanding indoor and outdoor environments. They are widely used in surveillance, perimeter security, industrial monitoring, and other applications requiring precise and repeatable positioning.
Now price of security camera with pan tilt zoom is reasonable, anything you need, please contact us.
As one of security camera monitoring companies, we will do our best to meet all the needs of customers.
